P. 9

GAME FENCE

                          12 ½ GA. FIXED-KNOT GAME FENCE

    Style                   Roll  Weight       Part #
                            Size
8/42/12                           220 lbs  8/42/12 660
9/49/12                   660 FT  252 lbs    9/49/12
10/60/6                   660 FT  205 lbs    10/60/6
10/60/12                  330 FT  288 lbs    10/60/12
13/48/6                   660 FT  234 lbs    13/48/6
13/75/6                   330 FT  269 lbs    13/75/6
17/75/6                   330 FT  318 lbs    17/75/6
17/75/12                  330 FT  229 lbs    17/75/12
20/96/6                   330 FT  386 lbs    20/96/6
20/96/12                  330 FT  276 lbs    20/96/12
23/120/6                  330 FT  492 lbs    23/120/6
                          330 FT

**Other items available, please inquire.
20/96/6 – 20 is the # of horizontal wires /96 is the height in inches /6 is the vertical wire spacing

*Top & Bottom wire        - 12 ½ ga -179 k tensile strength -1350 lbs breaking load -.85 oz sq.ft.
*Intermediate line wires  - 12 ½ ga -125 k tensile strength -9430 lbs breaking load -.85 oz sq.ft.
*Stay wires               - 13 ga -125 k tensile strength -4380 lbs breaking load -.85 oz sq.ft.

                                                          Section B
                                                             Page 1

                                                          1/6/2016
