Page 12 - Phoenix Fence Catalouge
P. 12
HORSE FENCE
12 ½ GA. Horse Fence Stock Roll Size Weight Part #
13/48 4’ High Horse Fence Y 100 FT 116 lbs 48 HF
16/60 5’ High Horse Fence Y 100 FT 143 lbs 60 HF
19/72 6’ High Horse Fence Y 100 FT 170 lbs 72 HF
13/48 – 13 is the # of horizontal wires, 48 is the height in inches
2" x 4" openings
Top/Bottom wires - 10-gauge class 1 galvanized wire
Line/Stay wires – 12 ½ gauge class 1 galvanized wire
Non-Climbable LAWN FENCE
Welded Lawn Fence
36” High Y 100 FT 74 lbs 36 LF
48” High Y 100 FT 98 lbs 48 LF
60” High Y 100 FT 122 lbs 60 LF
72” High Y 100 FT 146 lbs 72 LF
*Top, bottom, vertical wires are 12 ½ GA galvanized wire with Class 3 coating
*Tension curves in the 2" x 4" openings to keep tight
Section B1 Page 3
