FASTENERS

"U" Bolts - Galvanized Stock Weight Part #
1/2" c/w Nuts

1 7/8" O.D. Y .50 lbs 178 UB
2 3/8" O.D. Y .55 lbs 238 UB
2 7/8" O.D. Y .60 lbs 278 UB

3 1/2" O.D. Y .70 lbs 312 UB

Bare Steel Base Plates
5/8" Holes

3 5/8” X 3 5/8” X 1/4” - 4 Hole Y 2.00 lbs 358-358 BP

4 1/2" X 4 1/2” X 1/4" - 4 Hole Y 2.30 lbs 45-45 BP
6" X 6" X 1/4" - 4 Hole Y 2.50 lbs 6-6 BP

4" X 6" X 1/4" - 2 Hole Y 1.60 lbs 4-6 BP
8" X 8" X 3/8" - 8 Hole Y 6.10 lbs 8-8 BP
10" X 10" X 3/8" - 8 Hole Y 9.50 lbs 10-10 BP

Galvanized Base Plates
“Import”

4" X 6" X 1/4" - 4 Hole Y 2.10 lbs 4-6 BPI

6" X 6" X 1/4" - 4 Hole Y 2.30 lbs 6-6 BPI
8" X 8" X 3/8" - 4 Hole Y 4.00 lbs 8-8 BPI

Add For Welding Base Plates AWBP

Turnbuckles

3/8" X 10 ½” Alum. Eye & Eye Y .61 lbs ST
3/8" X 6" Malleable Iron, Hook & Eye Y 1.00 lbs DFT

Truss Rod Assemblies
(No Brace Bands)
3/8" x 12' Galv. Truss Rod Y 4.51 lbs TRO

3/8” x 1" Truss Tightener Y .59 lbs TRTO
